SuppressAll FS8100 Automatic Fire Suppression System

SuppressAll™ Model FS8100 — Fully contained automatic aerosol fire suppression system. Alarming, detection, fire suppression, and communications all in one.

Designed for smaller enclosures. Installs on ceiling or wall. Built-in siren alerts personnel; wireless communication notifies contacts via SMS, cellular, and email. Suppression generator uses thermodynamic energy harvesting (no external power). Alarm/strobe use rechargeable 12V sealed lead-acid battery with charger. Powder-coated steel housing. Made in the USA.

Aerosol fire suppression generator

• Total weight: 13.6 lbs · Compound weight: 4.4 lbs
• Discharge time: 60 seconds · Activation: thermodynamic harvesting
• 15-year shelf life on aerosol generator
• Part #: FS4301

Siren / Strobe

• 95 dB at 100 cm · 150 flashes per minute
• 12V sealed lead-acid battery + charger included

Detection and power source

• IP67 · Self-resetting · Trigger 25V, 3A · Lifetime: 15 years
• Max protected area: 215 sq.ft · Operating temp: −55°C to +90°C
• Pre-warning 65°C (149°F) · Actuation 85°C (185°F)

Communications — Proteus DB Cloud-Ready Digital Bridge

• 802.11b/g Wi-Fi · Setup from smartphone or PC
• Multi-email / phone alerts · JSON data logging
• No monthly subscription for text/email alerts
• Steel enclosure: 15″ × 11″ × 5″ · 12.5 lbs

Lead times may apply.

Hazard / Shipping Information (SDS)

• Product: SUPPRESSALL Condensed Aerosol Generators
• Hazard class: Flammable Solids, 4.1
• UN Number: 3178
• Proper shipping name: Flammable solid, inorganic, n.o.s. (fire suppressant containing potassium nitrate)
• Packing Group: III
• 24-Hour Emergency: 1-800-564-8611 (FSI) · Intl: +1-847-419-3700

Handling notes: Store in temperate conditions. Avoid shock, electric currents, static discharge, excessive heat, and extended storage above 65°C. Division 4.1 articles present no significant hazard as packaged for transport. Full Safety Data Sheet (SDS) is available — contact us to request the current SDS PDF.
