SuppressAll FS4400 Automatic or Manual Deployment System

SuppressAll™ FS4400 — Detection and suppression in a single unit. Automatic and manual activation.

Sold with FS10009 wall-mount bracket. Optional magnetic mount (RCHNL7F) available separately.

FS4400 unit specifications

• Total weight: 13.6 lbs · Compound weight: 4.4 lbs
• Discharge time: 60 seconds
• Activation: electrical via thermodynamic harvesting or manual pull-pin
• Part #: FS4400

Detection module

• No external energy source required — thermodynamic energy harvesting
• Protection: IP67
• Trigger pulse: 25V, 3A
• Operational lifetime: 15 years · Maintenance free
• Pre-warning at 65°C (149°F) · Actuation at 85°C (185°F)

Bracket (included FS10009)

• Weight: 5.4 lbs · Height 7.5″ · Width 12.0″ · Depth 8.25″
• Composition: ST 37 SAE1020 powder-coated steel

Made in the USA. Lead times may apply.

“When seconds count, pull the pin and throw it in!”

Hazard / Shipping Information (SDS)

• Product: SUPPRESSALL Condensed Aerosol Generators
• Hazard class: Flammable Solids, 4.1
• UN Number: 3178
• Proper shipping name: Flammable solid, inorganic, n.o.s. (fire suppressant containing potassium nitrate)
• Packing Group: III
• 24-Hour Emergency: 1-800-564-8611 (FSI) · Intl: +1-847-419-3700

Handling notes: Store in temperate conditions. Avoid shock, electric currents, static discharge, excessive heat, and extended storage above 65°C. Division 4.1 articles present no significant hazard as packaged for transport. Full Safety Data Sheet (SDS) is available — contact us to request the current SDS PDF.
