Redline Surge Max — high-output surface-mount warning module with 36 tri-color LEDs.
On Max, the green wire is Warning Mode 3 for both dual-color and tri-color. Max tri-color factory default is Color 3 with FP#18 Steady Scene. Max dual-color default is Color 1 alt. 2. Full-size Surge dual-color (not Max) is the one with no green Mode 3 (RED+WHITE).
LEDs: 36 tri-color — Amber/White, Red/Blue/Amber, or Red/Blue/White
Dimensions: 5.22" × 1.88" × 0.46"
Power: 12–24V DC | Max 2.24A @12V | Peak 26.88W | Fuse 3A
Certifications: SAE J595 Class 1, SAE J845 Class 1, ECE R10, ECE R65, CISPR 25 Class 3, IPX7, CA Title 13
